PIPE SDR 11 PP-R
length of pipes = 4 m
Recognizable by four blue stripes.
Suitable for cold water and air conditioning.
ISO 15874 class 1/6, 2/4, 4/6
DIN 8077/8078 20°C/10 bar.
| Article | d x s | di | l/m | DN | kg |
|---|---|---|---|---|---|
| 5155 20050 | 20 x 1,9 | 16,2 | 0,205 | 15 | 0,452 |
| 5155 20051 | 25 x 2,3 | 20,4 | 0,328 | 20 | 0,688 |
| 5155 20052 | 32 x 2,9 | 26,2 | 0,531 | 25 | 1,120 |
| 5155 20053 | 40 x 3,7 | 32,6 | 0,834 | 32 | 1,728 |
| 5155 20054 | 50 x 4,6 | 40,8 | 1,307 | 40 | 2,676 |
| 5155 20055 | 63 x 5,8 | 51,4 | 2,075 | 50 | 4,224 |
| 5155 20056 | 75 x 6,8 | 61,4 | 2,941 | – | 5,964 |
| 5155 20057 | 90 x 8,2 | 73,6 | 4,254 | 65 | 8,528 |
| 5155 20058 | 110 x 10,0 | 90,0 | 6,362 | 80 | 12,680 |
| 5155 20059 | 125 x 11,4 | 102,2 | 8,199 | 100 | 16,384 |
